MAXVAC SUPRA SV1-825-MBS - $5,400.00 USD excl. VAT
The SV1-825-MBS is a compact industrial vacuum fitted with a side-channel turbine, situated at the back under a sturdy metal casing. The turbine has a vacuum breaker safety valve, installed as standard. The filter chamber contains a large surface polyester filter, certified as M Class (1-micron filtration efficiency), ideal for working with even the finest dust. In this model of the Supra three-phase range, a different filter can be installed depending on the professional application. Teflon water-repellent filters, Nomex 250°C resistant filters, and filters with PTFE treatment for more binding and difficult dust are also available. The unit can be fitted with an H14 absolute filter on demand. The SV1-825-MBS industrial vacuum is equipped with a large 45 Lt detachable container on wheels that allows the operator to empty the vacuumed material easily. Disposable collection bags can also be used. A floating system can be provided in the container to vacuum liquids in complete safety.
Capacity | 45 L |
---|---|
Dimensions | 550 x 900 x 1120 mm |
Filter Class | M Class (EN 60336-2-69) |
Filter Cleaning | Manual Shaker |
Filter Media | Polyester |
Filter Surface Area | 22,000 cm² |
Filter Type | Star filter |
IP Rating | 55 |
Insulation Class | F |
Max Air-Flow (incl. filters) | 340 m³/h |
Max Depression | 250 mBar |
Noise Level | 72 dB |
Power | 3 kW / 4 HP |
Relief Valve | Optional |
Vacuum in Continuous Run | 230 mBar |
Voltage | 400 Volt |
Warranty | 12 Months |
Weight | 80 Kg |
Ø Inlet | 70 mm |
